Drum 70mm DIN 3415 Shoe Testing Machine Velcro Fatigue Tester

Name: Drum 70mm DIN 3415 Shoe Testing Machine Velcro Fatigue Tester
Brand: GESTER
Price: 1 USD

China Drum 70mm DIN 3415 Shoe Testing Machine Velcro Fatigue Tester factory

Brand Name : GESTER

Model Number : GT-K19

Certification : CE, ISO

Place of Origin : China

MOQ : 1 set

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 200 set/month

Delivery Time : 10-30 days

Packaging Details : wooden packaging

Keyword : Velcro Fatigue Tester

Service : Perfect after-sales service

Name : Hook and Loop Fatigue Tester

Advantage : factory direct sale

Type : Footwear Testing Equipments

Warranty period : 1 year

Contact Now

DIN 3415 Footwear Testing Equipments Hook and Loop Fatigue Tester

Product Introduction

Application:

Hook and Loop Fatigue Tester is applicable for repeatedly open and close motion for touch and close fasteners.

Standards:

DIN 3415, BS EN ISO 22776, BS EN ISO 22777

SATRA TM123, GB/T3903.20, GB/T3903.21

Principle

Install the hook and annular respectively on two rollers of this device. Stick them together under certain load and to generate repeated opening and closing motion through a certain times of forward and reversal rotating. After that, remove the sample and determine its peeling and shear strength testing on tensile tester.

Key Specifications

Model	GT-K19
Control method	LCD Touch screen controlled
Sample dimension	Length 540±10mm, width: 20~50mm
Upper idling drum	Diameter 162.5±0.5mm
Under driven drum	Diameter 160±0.5mm
Drum width	70mm
Clamp slot	Width 4mm, length 55±2mm
Test speed	60±5r/min
Reversal intervals	30±5 s
Test load	1±0.1N/mm
Test times	5000 cycles
Power supply	1∮AC 220V 50/60HZ
Dimensions( L x W x H )	55 cm ×45 cm ×65 cm
Weight	55kg
Standards	DIN 3415, BS EN ISO 22776, BS EN ISO 22777 SATRA TM123, GB/T3903.20, GB/T3903.21,GB/T 23315

Standard Accessories:

10N Weights	1 pc	To exert load on rotating wheel
20N Weights	1 pc	To exert load on rotating wheel
Power Line	1 pc	Current transport

Optional Accessories:

Press Roller	Optional	Diameter 100 mm
Universal Tensile Tester	Optional	Peeling and shear strength test
